BMW M135i xDRIVE: TECHNICAL DATA

THE 1BMW M135i xDRIVE: TECHNICAL DATA

BMW M135i xDRIVE TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1600
Max. permissible weight in kg 2085
Permitted load in kg 560
Permitted axle load front/rear in kg 1,120/1,020
Luggage capacity min. (seats up or roof down) in l 380
Luggage capacity max. (seats down or roof up) in l 1200
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1,998
Stroke/bore in mm 94.6/82.0
Engine power in kW (hp) at 1/min 225(306)/5,000-6,250
Engine torque (Nm) at 1/min 450/1,750-4,500
Compression ratio : 1 9.5

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 4.8
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 9.3
Extra-urban in l/100 km 6.4
Combined in l/100 km 7.5
CO2 combined emissions in g/km 171
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 50

Wheels

Tyre dimensions front 235/35 R19
Tyre dimensions rear 235/35 R19
Wheel dimensions and material front 8J x 19 inches, light alloy
Wheel dimensions and material rear 8J x 19 inches, light alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

Fuel consumption and CO2 emissions of the BMW M135i xDrive.

  • BMW M135i xDrive:
    Fuel consumption in l/100 km (combined): 7.5
    CO2 emissions in g/km (combined): 171

    Images show optional equipment, screens and displays depend on equipment options.

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tyres available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at https://www.dat.de/angebote/verlagsprodukte/leitfaden-kraftstoffverbrauch.html.

    All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
