TECHNICAL DATA OF THE NEW BMW X3.
Select model
- BMW X3 sDrive20i
- BMW X3 xDrive30i
- BMW X3 xDrive30e
No search result found. Please try another input
| Unladen weight EU in kg | 1,785 |
|---|---|
| Max. permissible weight in kg | 2,400-2,330 |
| Permitted load in kg | 690-620 |
| Permitted axle load front/rear in kg | 1,070/1,410-1,400 |
| Luggage capacity min. (seats up or roof down) in l | 550 |
| Luggage capacity max. (seats down or roof up) in l | 1,600 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,400 |
| Trailer load 12% (braked) in kg | 2,400 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,597 |
| Stroke/bore in mm | 75.6/82.0 |
| Engine power in kW (hp) at 1/min | 135/5,000-5,500 |
| Engine torque (Nm) at 1/min | 250/2,000-4,400 |
| Compression ratio : 1 | 8.9 |
| Top speed in km/h | 215 |
|---|---|
| Top speed fully electric in km/h | - |
| Acceleration 0–100 km/h in s | 8.4 |
| Urban in l/100 km | 8.3 |
|---|---|
| Extra-urban in l/100 km | 6.7 |
| Combined in l/100 km | 7.3 |
| CO2 combined emissions in g/km | 192-172 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 65 |
| Tyre dimensions front | 245/50 R 19 |
|---|---|
| Tyre dimensions rear | 245/50 R 19 |
| Wheel dimensions and material front | 7.5 J × 19 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 19 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | 0.4 |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (hp) | - |
|---|---|
| Electric engine torque (Nm) | - |
| Combined power kW (hp) | - |
|---|---|
| Combined torque Nm | - |
| Unladen weight EU in kg | 1,885 |
|---|---|
| Max. permissible weight in kg | 2,450 |
| Permitted load in kg | 640 |
| Permitted axle load front/rear in kg | 1,160/1,400 |
| Luggage capacity min. (seats up or roof down) in l | 550 |
| Luggage capacity max. (seats down or roof up) in l | 1,600 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 2,400 |
| Trailer load 12% (braked) in kg | 2,400 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 185/5,200-6,500 |
| Engine torque (Nm) at 1/min | 350/1,450-4,800 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 240 |
|---|---|
| Top speed fully electric in km/h | - |
| Acceleration 0–100 km/h in s | 6.6 |
| Urban in l/100 km | 9.0 |
|---|---|
| Extra-urban in l/100 km | 7.2 |
| Combined in l/100 km | 7.9 |
| CO2 combined emissions in g/km | 194-173 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 65 |
| Tyre dimensions front | 245/50 R 20 |
|---|---|
| Tyre dimensions rear | 275/40 R 20 |
| Wheel dimensions and material front | 8 J × 20 inches, light-alloy |
| Wheel dimensions and material rear | 9.5 J × 20 inches, light-alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | 0.4 |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (hp) | - |
|---|---|
| Electric engine torque (Nm) | - |
| Combined power kW (hp) | - |
|---|---|
| Combined torque Nm | - |
| Unladen weight EU in kg | 2,065 |
|---|---|
| Max. permissible weight in kg | 2,600 |
| Permitted load in kg | 610 |
| Permitted axle load front/rear in kg | 1,200/1,515 |
| Luggage capacity min. (seats up or roof down) in l | 450 |
| Luggage capacity max. (seats down or roof up) in l | 1,500 |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | - |
| Trailer load 12% (braked) in kg | 2,000 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1.998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 135(184)/5000-6500 |
| Engine torque (Nm) at 1/min | 300/1350-4000 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 210 |
|---|---|
| Top speed fully electric in km/h | 135 |
| Acceleration 0–100 km/h in s | 6.1 |
| Urban in l/100 km | - |
|---|---|
| Extra-urban in l/100 km | - |
| Combined in l/100 km | 2.6-2.0 |
| CO2 combined emissions in g/km | 59-45 |
| Electricity consumption, combined in kWh/100km | 19.3 |
| Tank capacity, approx. in l | 50 |
| Tyre dimensions front | 245/50 R 20 |
|---|---|
| Tyre dimensions rear | 275/40 R 20 |
| Wheel dimensions and material front | 8 J × 20 inches, light-alloy |
| Wheel dimensions and material rear | 9.5 J × 20 inches, light-alloy |
| Electric range in km | Up to 41 |
|---|---|
| Growth capacity of lithium–ion battery in kWh | 12 |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | 2.7-2.4 |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | 4.0 |
| Electric engine power kW (hp) | 80 (109)/- [10] |
|---|---|
| Electric engine torque (Nm) | 265 |
| Combined power kW (hp) | 215 (292) [9] |
|---|---|
| Combined torque Nm | 420 [9] |
Fuel consumption and CO2 emissions of the BMW X3.
BMW X3 xDrive30e:
Fuel consumption in l/100 km (combined): 2.6-2.0
CO2 emissions in g/km (combined): 59–44
BMW X3 xDrive30i:
Fuel consumption in l/100 km (combined): 8.5-7.6
CO2 emissions in g/km (combined): 194–173
BMW X3 M40i:
Fuel consumption in l/100 km (combined): 9.5-8.7
CO2 emissions in g/km (combined): 217–199
Official data on fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP specifications take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
Fuel consumption and CO2 emissions of the BMW X3.
- Disclaimer reference invalid
FUEL CONSUMPTION AND CO2 EMISSIONS OF THE BMW X3.
BMW X3 xDrive30e:
Fuel consumption in l/100 km (combined): 2.6-2.0
CO2 emissions in g/km (combined): 59-45
BMW X3 xDrive30i:
Fuel consumption in l/100 km (combined): 8.5-7.6
CO2 emissions in g/km (combined): 194-173
BMW X3 sDrive20i:
Fuel consumption in l/100 km (combined): 7.3
CO2 emissions in g/km (combined): 166
The figures for performance, consumption and CO2 emissions refer to vehicles with standard transmission.
[1] Performance data of petrol engines apply to vehicles using RON 98 fuel. Fuel consumption data apply to vehicles using reference fuels in accordance with EU Regulation 715/2007. Unleaded RON 91 and higher with a maximum ethanol content of 10% (E10) may also be used. BMW recommends RON 95 fuel. For high-performance automobiles, BMW recommends RON 98 fuel.
[2] For plug-in hybrid: Electric drive depending on battery charging level.
[3] For plug-in hybrid: At temperatures below freezing, the fully electric drive system is only available after a few kilometres of driving, once the battery has heated to operational temperature.
[4] Official data for fuel consumption, CO2 emissions, power consumption and electric range was determined in accordance with the prescribed measuring procedure and corresponds to European Regulation (EC) 715/2007 in the applicable version. For ranges, data determined as per WLTP takes into account any optional equipment (available on the German market in this case). For vehicles that have been newly type approved since 1 January 2021, only the official data according to WLTP exists. In addition, NEDC values are deleted from the certificates of conformity as of 1 January 2023 by EC regulation 2022/195.
For more information about NEDC and WLTP measuring procedures visit www.bmw.com/wltp
Further information about fuel consumption and official model-specific CO2 emissions of new passenger cars can be found in the "Guideline for fuel consumption, CO2 emissions and electric power consumption for new passenger cars", available free of charge at all points of sale, at the Deutsche Automobil Treuhand GmbH (DAT), Hellmuth-Hirth-Str. 1, 73760 Ostfildern-Scharnhausen, Germany, and under https://www.dat.de/co2/.
[5] For plug-in hybrid: Weighted, combined (EC AC Charge Weighted)
[6] Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.
[7] The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.
[8] The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.
[9] Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value). Electric drive depending on battery charging level.
[10] Provisional figures; any missing figures were unavailable at the time of publication.
