BMW X3 M Automobiles, technical data



Technical data.

BMW X3 M AUTOMOBILES.Technical data.


Select model


Unladen weight EU in kg 2045
Max. permissible weight in kg 2500
Permitted load in kg 530
Permitted axle load front/rear in kg 1,185/1,425
Luggage capacity min. (seats up or roof down) in l 550
Luggage capacity max. (seats down or roof up) in l 1600
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -


Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in kW (hp) at 1/min 375(510)/6,250
Engine torque (Nm) at 1/min 600/2,600-5,950
Compression ratio : 1 9.3


Top speed in km/h 285
Acceleration 0–100 km/h in s 4.1
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km 14.1
Extra-urban in l/100 km 8.6
Combined in l/100 km 10.6
CO2 combined emissions in g/km 244
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 65


Tyre dimensions front 255/40 R21
Tyre dimensions rear 265/40 R21
Wheel dimensions and material front 9.5J x 21 inches, light alloy
Wheel dimensions and material rear 10J x 21 inches, light alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (hp) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (hp) -
Combined torque Nm -

Fuel consumption and CO2 emissions.

  • BMW X3 M40i:
    Fuel consumption in l/100 km (combined): 8.9
    CO2 emissions in g/km (combined): 204

    The values of fuel consumptions, CO2 emissions and energy consumptions shown were determined according to the European Regulation (EC) 715/2007 in the version applicable at the time of type approval. The figures refer to a vehicle with basic configuration in Germany and the range shown considers optional equipment and the different size of wheels and tyres available on the selected model.

    The CO2 efficiency specifications are determined according to Directive 1999/94/EC and the European Regulation in its current version applicable. The values shown are based on the fuel consumption, CO2 values and energy consumptions according to the NEDC cycle for the classification.

    For further information about the official fuel consumption and the specific CO2 emission of new passenger cars can be taken out of the „handbook of fuel consumption, the CO2 emission and power consumption of new passenger cars“, which is available at all selling points and at

    All technical data are indicative only and varies as per market and configuration. For more information, please check with your local dealer for all fuel consumption and CO2 emissions.
