BMW 5 SERIES SEDAN: ENGINES &
TECHNICAL DATA
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Sedan.
THE 5BMW 5 SERIES SEDAN: ENGINES &<br> TECHNICAL DATA
Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Sedan.
BMW 5 SERIES SEDAN: TECHNICAL DATA.
Select model
- 530e M Sport
- 530i M Sport
No search result found. Please try another input
| Unladen weight EU in kg | 1910 |
|---|---|
| Max. permissible weight in kg | 2505 |
| Permitted load in kg | 670 |
| Permitted axle load front/rear in kg | 1035/1305 |
| Luggage capacity min. (seats up or roof down) in l | 410 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | - |
| Trailer load 8% (braked) in kg | - |
| Trailer load 12% (braked) in kg | - |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1998 |
| Stroke/bore in mm | 94.6/82 |
| Engine power in kW (hp) at 1/min | 135(184)/5,000-6,500 |
| Engine torque (Nm) at 1/min | 300/1,350-4,000 |
| Compression ratio : 1 | 11 |
| Top speed in km/h | 230 |
|---|---|
| Acceleration 0–100 km/h in s | 5.9 |
| Top speed fully electric in km/h | 140 |
| Urban in l/100 km | - |
|---|---|
| Extra-urban in l/100 km | - |
| Combined in l/100 km | 2.3 |
| CO2 combined emissions in g/km | 53 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 40 |
| Tyre dimensions front | 245/40 R 19 |
|---|---|
| Tyre dimensions rear | 275/35 R 19 |
| Wheel dimensions and material front | 8 J × 19 inches, light alloy |
| Wheel dimensions and material rear | 9 J × 19 inches, light alloy |
| Electric range in km | 54 |
|---|---|
| Growth capacity of lithium–ion battery in kWh | 12 |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | 2.6 |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | 3.6 |
| Electric engine power kW (PS) at 1/min | 80(109)/3,140 |
|---|---|
| Electric Engine torque (Nm) at 1/min | 265/100-2,500 |
| Combined power kW (PS) | 215 (292) |
|---|---|
| Combined torque Nm | 420 |
| Unladen weight EU in kg | 1700 |
|---|---|
| Max. permissible weight in kg | 2305 |
| Permitted load in kg | 680 |
| Permitted axle load front/rear in kg | 1115/1230 |
| Luggage capacity min. (seats up or roof down) in l | 530 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | - |
| Trailer load 8% (braked) in kg | - |
| Trailer load 12% (braked) in kg | - |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1998 |
| Stroke/bore in mm | 94.6/82 |
| Engine power in kW (hp) at 1/min | 185(252)/5,200-6,500 |
| Engine torque (Nm) at 1/min | 350/1,450-4,800 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 6.4 |
| Top speed fully electric in km/h | - |
| Urban in l/100 km | - |
|---|---|
| Extra-urban in l/100 km | - |
| Combined in l/100 km | 6.7 |
| CO2 combined emissions in g/km | 154 |
| Electricity consumption, combined in kWh/100km | - |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 245/40 R 19 |
|---|---|
| Tyre dimensions rear | 275/35 R 19 |
| Wheel dimensions and material front | 8 J × 19 inches, light alloy |
| Wheel dimensions and material rear | 9 J × 19 inches, light alloy |
| Electric range in km | - |
|---|---|
| Growth capacity of lithium–ion battery in kWh | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h | - |
| Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h | - |
| Electric engine power kW (PS) at 1/min | - |
|---|---|
| Electric Engine torque (Nm) at 1/min | - |
| Combined power kW (PS) | - |
|---|---|
| Combined torque Nm | - |
FUEL CONSUMPTION AND CO2 EMISSIONS.
BMW 530e**:
Fuel consumption in l/100 km (combined): 1,8–1,3
CO2 emissions in g/km (combined): 41–30
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.
