BMW 5 Series Sedan eDrive (G30) Phytonic Blue metallic, rear view parking in front of a building

THE 5

BMW 5 SERIES SEDAN: ENGINES &
TECHNICAL DATA

Discover the powerful petrol, diesel and hybrid engines as well as the dimensions and other technical data of the BMW 5 Series Sedan.

Read more
THE 5BMW 5 SERIES SEDAN: ENGINES &<br> TECHNICAL DATA

BMW 5 SERIES SEDAN: TECHNICAL DATA.

Select model

Weight

Unladen weight EU in kg 1700
Max. permissible weight in kg 2305
Permitted load in kg 680
Permitted axle load front/rear in kg 1115/1230
Luggage capacity min. (seats up or roof down) in l 530
Luggage capacity max. (seats down or roof up) in l -
Trailer load (unbraked) in kg -
Trailer load 8% (braked) in kg -
Trailer load 12% (braked) in kg -

Engine

Cylinders/valves 4/4
Capacity in ccm 1998
Stroke/bore in mm 94.6/82
Engine power in kW (hp) at 1/min 185(252)/5,200-6,500
Engine torque (Nm) at 1/min 350/1,450-4,800
Compression ratio : 1 10.2

Performance

Top speed in km/h 250
Acceleration 0–100 km/h in s 6.4
Top speed fully electric in km/h -

Fuel consumption

Urban in l/100 km -
Extra-urban in l/100 km -
Combined in l/100 km 6.7
CO2 combined emissions in g/km 154
Electricity consumption, combined in kWh/100km -
Tank capacity, approx. in l 59

Wheels

Tyre dimensions front 245/40 R 19
Tyre dimensions rear 275/35 R 19
Wheel dimensions and material front 8 J × 19 inches, light alloy
Wheel dimensions and material rear 9 J × 19 inches, light alloy

Range and charging

Electric range in km -
Growth capacity of lithium–ion battery in kWh -
Charging time 3,7 kW/16 A, BMW i Wallbox (80 %) h -
Charging time 3,7 kW/16 A, BMW i Wallbox (100 %) h -

Electric engine

Electric engine power kW (PS) at 1/min -
Electric Engine torque (Nm) at 1/min -

Combined system power

Combined power kW (PS) -
Combined torque Nm -

FUEL CONSUMPTION AND CO2 EMISSIONS.

BMW 530e**:
Fuel consumption in l/100 km (combined): 1,8–1,3
CO2 emissions in g/km (combined): 41–30



Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp



** At temperatures below 0 degrees Celsius, purely electric driving mode of this plug-in hybrid will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few kilometers.
